TC102 Base Metal Thermocouple with Metal Protection Tube

Heavy-Duty Type K & J Thermocouple for Furnaces, Process Equipment and High-Temperature Industrial Applications

Built for demanding industrial temperature measurement, the TC102 Base Metal Thermocouple combines a Type K or Type J sensing element with a heavy-duty metal protection tube for dependable service in furnaces, high-temperature ovens, aluminum processing, chemical plants, oil and gas, incineration and combustion processes. Choose from beaded or MGO-PAC elements, multiple protection-tube materials, threaded or flanged process connections, and several connection-head options to match new OEM equipment or existing plant installations

Heavy-Duty Metal Protection Tube

Protects the thermocouple element in demanding industrial and high-temperature process environments

Type K & J Thermocouple

Available with common base-metal thermocouple types for a wide range of industrial temperature applications

Multiple Protection Tube

Choose from 304, 310, 316 or 446 stainless steel, Inconel 600 or Inconel 601 to suit the process environment

High-Temperature

Depending on thermocouple type and protection tube selection, configurations are available for temperatures up to 1260°C (2300°F).

Conical Tip for Aluminum Processing

A conical-tip configuration is available for anode baking and flue-wall applications in aluminum processing

Multiple Connection Head

Choose from general-purpose aluminum, stainless steel, cast iron, or explosion-proof connection heads to suit different installation environments

Download Datasheet

Quick Specifications

Thermocouple Type Type K,J
Measuring Element Single or Duplex
Element Construction Beaded thermocouple or MGO-PAC mineral-insulated
MGO-PAC Junction Grounded or Ungrounded
Beaded Junction Options Twist & TIG Weld, Insulated Hot Junction, or Standard TIG Weld
Beaded Wire Size 8, 14, 16 or 20 AWG
Ideal for
Industrial Furnaces
High-Temperature Ovens
Anode Baking Furnaces
Flue-Wall Temperature
Heat Treatment
Incinerators
Kilns & Ovens
OEM Process Heating
The TC102 Base Metal Thermocouple with Metal Protection Tube is designed for accurate temperature measurement in furnaces, high-temperature ovens, chemical processing, oil and gas, aluminum processing, incineration, and combustion applications. The strong protection tube safeguards the thermocouple element from harsh process conditions and delivers a practical, maintainable design suitable for industrial plants, original equipment manufacturer (OEM) systems, and maintenance, repair, and operations (MRO) replacement scenarios.
The TC102 is offered with Type K and Type J thermocouple elements in both single and duplex configurations. Depending on application requirements, the sensing element may be provided as a traditional beaded thermocouple or as a mineral-insulated MGO-PAC thermocouple. MGO-PAC variants are available with either grounded or ungrounded junctions, letting engineers to optimize response time, electrical isolation, and installation parameters.
A comprehensive range of metal protection tubes enables customization of the assembly to specific operating environments. Material options include 304, 310, 316, and 446 stainless steel, as well as Inconel 600 and Inconel 601. Pipe sizes, schedules, and element diameters are configurable to accommodate both new equipment and retrofit installations.
For aluminum-processing applications, the TC102 may be equipped with a conical tip for anode baking and flue-wall temperature measurement. Flat-tip protection tube configurations are also offered. Depending on the selected thermocouple type and protection tube, the assembly supports operation at temperatures up to 1260°C (2300°F).
Installation options comprise threaded process bushings, adjustable flanges, and flanged connections, as well as multiple connection head selections. General-purpose, stainless steel, Cast Iron and explosion-proof head configurations are available to address diverse plant requirements.
With configurable elements, protection tubes, process connections, and connection heads, the TC102 industrial thermocouple offers a multifaceted solution for both new OEM designs and replacement temperature sensors in existing process equipment.

Product Specifications

Review the standard specifications and available configuration options for the TC102 Industrial Thermocouple with metal Portection tube. Product dimensions, materials, temperature ratings, and optional features may vary depending on the selected configuration

Thermocouple TypeType K,J
Measuring ElementSingle or Duplex
Element ConstructionBeaded thermocouple or MGO-PAC mineral-insulated
MGO-PAC JunctionGrounded or Ungrounded
Beaded Junction OptionsTwist & TIG Weld, Insulated Hot Junction, or Standard TIG Weld
Beaded Wire Size8, 14, 16 or 20 AWG
Beaded Element InsulationRound or Oval Ceramic Insulators
Protection Tube MaterialsSS304, SS310, SS316, SS446, Inconel 600 or Inconel 601
Protection Tube / Pipe Size3/8", 1/2", 3/4" or 1" NPS
Pipe ScheduleSchedule 40, 80 or 160
Maximum TemperatureUp to 1260°C (2300°F) depending on thermocouple type and protection tube
Tip ConfigurationFlat Tip or Conical Tip
Process ConnectionNone, Process Bushing, Adjustable Flange or Thread-on Flange
Connection HeadAluminum, Stainless Steel, Cast Iron or Explosion-Proof options
Head TerminationCeramic Terminal Block

Spare Parts & Accessories

Complete your installation with compatible mounting accessories, connectors, and replacement components for the TC102 Thermocouple.

Image: Cast Iron-Connection Head

Cast Iron-Connection Head

TempoTech’s Thermocouple connection heads are enclosures designed to house the thermocouple junction and provide a safe, protected environment for the connections to the temperature measurement system. These heads are typically used in…

Find more…
Read
Image: KNE-Plastic Head

KNE-DIE CAST ALUMINUM HEAD

TempoTech’s Thermocouple connection heads are enclosures designed to house the thermocouple junction and provide a safe, protected environment for the connections to the temperature measurement system. These heads are typically used in…

Find more…
Read
Image: PT- Metal Thermocouple Protection Tube

PT- Metal Thermocouple Protection Tube

Tempotech Controls offers a variety of protection solutions for thermocouples, designed to ensure reliable temperature measurement in diverse industrial applications. Their range includes protection tubes made from high-performance materials like 310 Stainless…

Find more…
Read
Image: Stainless Steel Thermocouple Connection Head

Stainless Steel Thermocouple Connection Head

TempoTech’s Thermocouple connection heads are enclosures designed to house the thermocouple junction and provide a safe, protected environment for the connections to the temperature measurement system. These heads are typically used in…

Find more…
Read

Product Videos

Watch product overview, installation, and application videos for the TC102 Thermocouple

FerroSafe® series thermocouples | Tempotech Controls Inc

FerroSafe® series thermocouples for Molten Metal application

Read transcript

[00:00:05] Introducing the FerroSafe® series thermocouples, engineered for high-temperature accuracy and built for extreme molten metal environments.

[00:00:17] Designed specifically for the non-ferrous metal industries, this industrial sensor delivers precise temperature measurement where failure is not an option. It comes with various options, including a rugged handle, lead wire, and digital reader.

[00:00:28] At its core is a rugged metal sheath protected by our proprietary ceramic coating. This unique non-wetting layer ensures longer sensor life and reliable performance in direct molten metal contact.

[00:00:37] With a reduced tip for fast-response sensing and a thermal conductive coating for consistent readings, the FerroSafe responds in under 8 seconds—perfect for real-time process control.

[00:00:45] Available in Type K and Type N calibrations and built to ASM, IEC, and ANSI standards, these sensors meet Class 1 and Class 2 accuracy for high-confidence data when it matters most.

[00:01:06] Choose from coated or uncoated versions depending on your application needs, withstanding temperatures up to 900°C or 1600°F.

[00:01:14] FerroSafe: Precision, durability, and performance. Contact us today to learn more or request a quote. Visit our website to find more information.

Thermocouples de la série FerroSafe®

FerroSafe® series thermocouples for Molten Metal application

Read transcript

[00:05] Présentation des thermocouples de la série FerroSafe®, conçus pour une précision optimale et fabriqués pour des environnements extrêmes de métal en fusion.

[00:13] Conçu spécialement pour les industries des métaux non ferreux, ce capteur industriel fournit une mesure de température précise là où l'échec n'est pas une option. Disponible avec plusieurs options, y compris une poignée ergonomique, un câble de compensation, et un lecteur numérique.

[00:29] Au cœur de ce produit se trouve une gaine métallique robuste protégée par notre revêtement céramique exclusif. Cette couche unique non mouillable garantit une durée de vie prolongée et des performances fiables au contact direct du métal en fusion.

[00:43] Avec une pointe réduite pour une réponse thermique rapide et un revêtement thermiquement conducteur pour des relevés constants, le FerroSafe® réagit en moins de 8 secondes—idéal pour le contrôle des processus en temps réel.

[00:50] Disponible en étalonnage de Type K et Type N, et fabriqué selon les normes ASM, IEC et ANSI. Ces capteurs sont proposés avec des tolérances d'erreurs standard ou spéciales, garantissant des données fiables et précises lorsque la précision est essentielle.

[01:05] Choisissez entre des versions avec ou sans revêtement selon les exigences de votre application, résistant à des températures allant jusqu'à 900°C.

[01:13] FerroSafe® : Précision, durabilité, performance. Contactez-nous dès aujourd'hui pour en savoir plus sur notre série FerroSafe®. Visitez notre site web www.tempotechcontrols.com.

Configure This Product

Open the product configurator to select available options and prepare your configuration.

Configure Product

Frequently Asked Questions

Find answers to common questions about the TC102 Thermocouple

How do I select the correct protection tube material for temperature, oxidation and furnace atmosphere?+

For oxidizing atmospheres, consider 310 or 446 stainless steel, or Inconel 601 for more severe high-temperature service. For reducing atmospheres, Inconel 600 is generally preferred. 304 or 316 stainless steel may suit lower-temperature, less-corrosive applications. Always confirm compatibility with the furnace temperature and gas composition.

Should I specify a beaded thermocouple element or an MGO-PAC element for my furnace?+

Choose a beaded thermocouple element when a simple, economical construction and relatively fast response are priorities. The TC102 datasheet notes that beaded elements have low mass and therefore provide a fast response, but they are not recommended for highly oxidizing environments.Choose an MGO-PAC element when you need a more rugged construction with the thermocouple wires supported inside a mineral-insulated sheath. The TC102 is available with grounded or ungrounded MGO-PAC junctions, giving flexibility for different furnace and instrumentation requirements

How does protection tube diameter and Schedule 40, 80 or 160 affect sensor response and mechanical durability?+

A larger diameter or heavier-wall protection tube generally provides greater mechanical durability, but the additional mass can result in a slower temperature response. A lighter construction generally responds faster but provides less mechanical protection. For the TC102, Schedule 40, 80 and 160 protection-tube options are available. Selection should be based on the required mechanical protection, process conditions, and acceptable response time

What immersion length should be used to minimize temperature measurement error?+

A duplex thermocouple is useful when redundancy or two independent temperature signals are required from the same measurement point. The two elements can support separate control and monitoring systems or provide a backup signal if one measurement circuit fails. For applications requiring only one temperature signal, a single-element thermocouple is typically sufficient. The TC102 is available with single or duplex elements

Can the TC102 replace an existing furnace thermocouple while keeping the same flange, insertion length and connection head?+

Yes, The TC102 can be configured for replacement applications with different process connections, flange sizes, connection heads and extension lengths. When replacing an existing furnace thermocouple, provide the existing sensor’s thermocouple type, protection tube size and material, insertion length, flange or thread connection, and connection head details so the TC102 can be configured to match the installation as closely as possible

What causes premature protection tube or thermocouple failure in a furnace?+

Premature failure can occur when the protection tube material or thermocouple construction is not properly matched to the furnace temperature and process conditions. Excessive temperature, thermal cycling, oxidation, corrosive atmospheres, vibration, and mechanical stress can shorten sensor life. Selecting the correct protection tube material and construction for the actual furnace environment is important for reliable operation. The TC102 offers multiple stainless steel and Inconel protection tube options to accommodate different process requirements
