FSTC03- Our FerroSafe® series thermocouples are designed to meet extensive requirements of ferrous and Non ferrous molten metal industry.These thermocouples comes with heavy duty metal sheath coated with our internally developed coating with non wetting properties. Thermocouples are manufacture using Type K and N thermocouple wire and meets the class 2 and class 1 accuracy requirements. Ergonomic design handle for easy handling.
Key featrues:-
- Heavy metal sheath with Ceramic Coating for longer thermocouple life in moletn Metal
- Exhibits faster response time with thermal conductive coating makes it ideal for process control applications
- Mostly available with multiple thermocouple calibrations like type K ,N
- With and Without coating option avaiable
- Reduced Tip for Quick response
- Response Time : < 8 Sec
- Maximum Temperature : 900°C (1600°F)
- ASTM E608/608M/ IEC 60584 & ANSI MC 96.1 standard tolerance ±2.2°C or 0.75% of Reading whichever is greater
Application Note
In the metal processing industry, FerroSafe® thermocouples are a specialized type of temperature sensor commonly used to measure high temperatures in harsh environments. These thermocouples are designed with coatings that provide non-wetting properties, which are essential for preventing liquid (such as molten metal, oils, or cooling fluids) from adhering to the sensor surface. This is crucial in metal processing, where precise temperature measurement is critical, and the sensors are exposed to high temperatures, chemicals, and abrasive materials.
